C22SQ3AT2170B11
Description
Ener Frost® is the multicompressor racks series equipped with 2, 3 or 4 compressors, two of which are regulated by two vector inverters independently
Some features, minimum liquid level monitoring with alarm, compressors support floating frame,
high pressure switch on each compressor, low pressure switch and intervenction of inverter of the compressors in the event of an electronic failure
Electrical panel complete with magneto-thermal and differentials for compressor, compressor headers fan and crankcase heater, double safety transformer for auxiliaries, programmable controller
Enerfrost Units can be equipped with the following accessories:
Partial or total heat recovery.
Hot gas defrost direct or with reverse cycle
EC fans
Electronic remote monitoring or managment or WRC remote control
C22SQ3AT2170B11
Technical data
Cooling capacity
| Evaporating temperature |
-5°C | -10°C | -15°C |
|---|---|---|---|
| W | W | W | |
|
min |
6257,00 | 5239,00 | 4337,00 |
|
max |
30033,00 | 25147,00 | 20814,00 |
